Description

Key Benefits

• Easy calibration via magnetic card attached to the E‑Plate :contentReference[oaicite:2]{index=2}
• Simultaneous measurement of Na⁺, K⁺, and Cl⁻ on the same E‑Plate (single test) :contentReference[oaicite:3]{index=3}
• Requires only 22 µL of sample—minimizing patient discomfort, especially for pediatric and sensitive cases :contentReference[oaicite:4]{index=4}
• Highly compact and lightweight; fits within A5‑size footprint (~148 × 218 mm) :contentReference[oaicite:5]{index=5}
• Auto-start measurement via twin‑pipette; results printed in about 60 seconds :contentReference[oaicite:6]{index=6}
• Low maintenance with robust internal electrodes and sealed E‑Plate system :contentReference[oaicite:7]{index=7}

Core Features & Specifications

• Sample types: Whole blood, serum, plasma, urine :contentReference[oaicite:8]{index=8}
• Measurement parameters: Na⁺, K⁺, Cl⁻ measured potentiometrically via ISE :contentReference[oaicite:9]{index=9}
• Sample volume: 22 µL per test :contentReference[oaicite:10]{index=10}
• Measurement time: approx. 60 seconds; throughput ~60 tests/hour :contentReference[oaicite:11]{index=11}
• Display: LCD, 20 characters × 2 lines :contentReference[oaicite:12]{index=12}
• Built-in printer: 58 mm thermal printer, 36 characters wide :contentReference[oaicite:13]{index=13}
• External output: RS‑232C serial interface (9600 bps) :contentReference[oaicite:14]{index=14}
• Memory capacity: 50 measurement records :contentReference[oaicite:15]{index=15}
• Power supply: AC 100–240 V, 50/60 Hz; power consumption: ~40 VA :contentReference[oaicite:16]{index=16}
• Operating conditions: 10–30 °C; humidity 20–80 % RH non-condensing :contentReference[oaicite:17]{index=17}
• Dimensions: 135 mm (W) × 225 mm (D) × 138 mm (H); Weight: approx. 1.5 kg :contentReference[oaicite:18]{index=18}
• Warm‑up time: ~1 minute at 25 °C :contentReference[oaicite:19]{index=19}

Recommended Use Cases

• Hospitals and clinical labs needing rapid electrolyte testing
• Dialysis centers requiring consistent sodium and potassium monitoring
• Point-of-care areas with limited bench space or infrastructure
• Settings requiring integration with external systems via RS‑232
