Description

Key Benefits

• Extremely high throughput: up to 500 tests per hour (approx. 7 s per test) :contentReference[oaicite:1]{index=1}
• Large LCD touchscreen for intuitive menu navigation and result review :contentReference[oaicite:2]{index=2}
• Automatic strip detection and alignment improves efficiency and reduces errors :contentReference[oaicite:3]{index=3}
• Unique strip platform and waste tray design allows single-step cleaning and maintenance :contentReference[oaicite:4]{index=4}
• Autocalibration and automatic waste disposal reduce hands-on workload :contentReference[oaicite:5]{index=5}
• Auto-flagging of abnormal results improves QC oversight :contentReference[oaicite:6]{index=6}
• Versatile data transfer via RS‑232C and USB ports, LIS-compatible interfaces :contentReference[oaicite:7]{index=7}

Core Features & Specifications

• Throughput: 500 tests/hour; measuring cycle ~7 seconds per test :contentReference[oaicite:8]{index=8}
• Detection method: Reflectance photometry at 525 nm and 635 nm via photosensitive diode :contentReference[oaicite:9]{index=9}
• Memory capacity: Stores up to 2,000 test records :contentReference[oaicite:10]{index=10}
• Strip incubation time: 1 minute per strip :contentReference[oaicite:11]{index=11}
• Strip compatibility: Supports standard 108 × 5 mm reagent strips (8 to 14 parameters including microalbumin, creatinine, calcium) :contentReference[oaicite:12]{index=12}
• Waste capacity: Holds up to 150 used strips before emptying :contentReference[oaicite:13]{index=13}
• Display: Large LCD touchscreen approx. 11.5 × 9.0 cm :contentReference[oaicite:14]{index=14}
• Printer: Built-in thermal printer; port for external printer via parallel interface :contentReference[oaicite:15]{index=15}
• Connectivity: RS‑232C (for barcode reader or LIS), USB for data transfer, parallel port for external printer :contentReference[oaicite:16]{index=16}
• Lockout functions: Optional strip lockout, QC lockout, user lockout (up to 10 operator IDs) :contentReference[oaicite:17]{index=17}
• Operating conditions: 0–40 °C; ≤85 % RH; Storage: –5 to 50 °C; ≤90 % RH :contentReference[oaicite:18]{index=18}
• Power requirements: 100–240 VAC, 50–60 Hz :contentReference[oaicite:19]{index=19}
• Dimensions & Weight: 36.6 × 28.3 × 19.5 cm; approx. 4.0 kg :contentReference[oaicite:20]{index=20}

Recommended Use Cases

• High-volume clinical laboratories or hospital settings needing rapid urinalysis
• POCT settings with demand for fast turnaround and reliability
• Facilities requiring automated QC workflows and traceable result reporting
• Operations where minimal cleaning and maintenance are priorities

Additional Information

• Capacity to read strips with microalbumin, creatinine, and calcium expands diagnostic scope beyond standard parameters :contentReference[oaicite:21]{index=21}
• Preloaded interface languages (up to 8) support diverse user bases and regional locales :contentReference[oaicite:22]{index=22}
• Compact and lightweight design supports portability between testing stations or wards :contentReference[oaicite:23]{index=23}
