Description

Key Benefits :

High throughput: Capable of processing up to 360 tests per hour, facilitating quick turnaround times.
Comprehensive test menu: Supports a wide array of assays, including end-point, kinetic, and immunoturbidimetric tests.
Automated calibration and QC: Ensures consistent and accurate results with minimal manual intervention.
User-friendly interface: Features a touchscreen display and intuitive software for easy operation.
Compact design: Space-saving benchtop model suitable for various laboratory settings.
Core Features

System type: Fully automated, discrete, random access clinical chemistry analyzer
Throughput: 360 tests/hour (photometric); 600 tests/hour with optional ISE module
Sample types: Serum, plasma, urine, CSF, whole blood
Reagent handling: 50-position refrigerated reagent tray
Sample handling: 82-position sample tray; 2–70 µL pipetting range
Photometer: Multi-wavelength diffraction grating with 12 wavelengths (340, 376, 415, 450, 480, 505, 546, 570, 600, 660, 700, 750 nm)
Light source: Halogen lamp
Detector: Silicon photodiode
Calibration methods: Linear (1, 2, multi-point), exponential, logit-log, spline
Quality control: Onboard QC with Levey-Jennings plots and twin plots
Connectivity: USB, RS-232, TCP/IP; LIS/HIS compatible
Operating system: Windows-based with comprehensive data management software
Dimensions: 675 mm (W) x 840 mm (D) x 1120 mm (H)
Weight: Approximately 150 kg
Power supply: AC 220 V ± 10%, 50 Hz or AC 110 V ± 10%, 60 Hz
Power consumption: 800 VA
Water consumption: <10 liters/day Recommended Use Cases Medium to large clinical laboratories: High-volume testing environments requiring efficient and reliable analysis. Hospitals and diagnostic centers: Facilities needing a comprehensive solution for biochemical testing. Research institutions: Laboratories conducting biochemical research and analysis. Additional Information Maintenance: Features a 5-stage cleaning and 2-stage drying system for cuvettes. Reagent cooling: Onboard refrigeration to maintain reagent stability. Barcode reader: Optional barcode reader for reagents and samples. User training: Comprehensive training and support provided during installation.
