Description

Key Benefits

• Reliable and flexible testing for evolving workloads
• Low operating cost and easy Yes/No user interface :contentReference[oaicite:2]{index=2}
• SnapPak reagent‑and‑waste pack simplifies consumables handling :contentReference[oaicite:3]{index=3}
• Interchangeable electrodes allow easy configuration changes without tubing or reagent swaps :contentReference[oaicite:4]{index=4}
• Low maintenance: long-life electrodes, single-pump fluidic design, sealed waste/reagent handling :contentReference[oaicite:5]{index=5}
• Built-in QC program stores up to 35 values per level, flags out-of-range readings, and calculates trends automatically :contentReference[oaicite:6]{index=6}

Core Features & Specifications

• Sample size: 95 μL typical (whole blood, serum, plasma, urine, dialysate, QC) :contentReference[oaicite:7]{index=7}
• Analysis time: approx. 50 seconds per sample; throughput up to 60 samples/hour (45 with printout) :contentReference[oaicite:8]{index=8}
• Calibration: automatic one-point calibration with each sample; two-point calibration every four hours :contentReference[oaicite:9]{index=9}
• Measuring ranges (mmol/L): Na⁺ 40–205, K⁺ 1.5–15, Cl⁻ 50–200, Ca²⁺ 0.2–5.0, Li⁺ optional 0.1–6.0; adjustable per sample type :contentReference[oaicite:10]{index=10}
• Precision (CV): ≤1% for Na⁺/Cl⁻, ≤1.5% for K⁺, SD ≤0.02 mmol/L for Ca²⁺ and Li⁺ :contentReference[oaicite:11]{index=11}
• Display: dot-matrix, 2‑line by 16‑character display; built-in thermal printer (16 characters wide) :contentReference[oaicite:12]{index=12}
• Interface: RS‑232C serial port; data link to Roche COMPACT 2/3 blood gas analyzers :contentReference[oaicite:13]{index=13}
• Operating range: temperature 15–32 °C; humidity <85% non‑condensing :contentReference[oaicite:14]{index=14}
• Power: 110–240 V AC (50/60 Hz), self-adjusting; max 1.4 A consumption :contentReference[oaicite:15]{index=15}
• Dimensions: 33.5 × 31.5 × 29.5 cm (H×W×D); Weight: approx. 6 kg :contentReference[oaicite:16]{index=16}
• Certifications: CE (EN45014), CSA approved :contentReference[oaicite:17]{index=17}

Recommended Use Cases

• Hospitals and clinical laboratories handling electrolyte testing
• Dialysis centers requiring rapid sodium and potassium monitoring
• Near-patient and small-lab environments needing minimal setups and low-cost maintenance
• Settings integrating with Roche blood-gas analyzers (COMPACT 2/3) for combined panels

Additional Information

• ISETROL tri-level control solution requires no refrigeration and integrates with QC program :contentReference[oaicite:18]{index=18}
• SnapPak system ensures sealed handling of reagents and waste, minimizing contamination risk :contentReference[oaicite:19]{index=19}
• Flexible electrode configurations (up to seven) without tubing or reagent changes :contentReference[oaicite:20]{index=20}
